Klarity 100m 4K60 4:4:4 HDR 10bit, HDCP 2.2, 18G HDMI 2.0, 8x8 HDBaseT Matrix Kit
- Includes 8 HDBaseT Receivers with Optical S/PDIF & ARC support
- HDBaseT DSC Technology
- Up to 100m/328ft 4K60 4:4:4 18Gbps 10bit HDR
- HDCP 2.2 Compliant
- 8x HDMI 2.0 Inputs + 8x HDBaseT Outputs
- 2x HDMI Loop-Through
- 4K to 1080p built-in Downscaler on all output ports
- Optical S/PDIF & Stereo Phono Input
- 8x Optical S/PDIF Outputs, 8x Stereo Phono Outputs
- HDR10 & HDR10+
- Supports all known audio formats including: Dolby Atmos®, DTS:X®, Dolby TrueHD®, Dolby Digital Plus®, DTS-HD® Master Audio
- HDBaseT PoE - Receivers require no power
- Includes: 1 Standard remote control, 1 Easy remote control (easy remote has 9 buttons. When at any TV, if you want to watch for example Source 2, just aim the remote at that TV and press 2 and it will automatically show Source 2 on that TV).
- Directional IR: for example, you are watching Input 3 at TV2, any IR command you give will only send that IR signal to Input 3.
- 3 Years Warranty
Overview
To support HDBaseT 4K60 4:4:4 HDR 18G HDMI 2.0, DSC or CSC is required.
The world-renowned company, VESA®, developed DSC for visually lossless compression. This is an HDBaseT approved lossless compression whereas CSC is not approved or recognized by HDBaseT and is classed as a "Third Party Compression".
DSC only affects 4K60 4:4:4 signals. All other signals are uncompressed. It is also an extremely light compression which is done line-by-line.
In comparison, CSC uses Chroma subsampling and bit depth downsampling to reduce the amount of colour in the video signal by maintaining the luminance. This removes pixel bits, up to 50% in 4:4:4 during CSC compression, which cannot be recovered at the HDBaseT Receiver. Once a large part of the colour and dynamic range has been removed, it is impossible to get them back. DSC's line-by-line compression does not suffer from this permanent loss.
Furthermore, text is displayed correctly with DSC but CSC suffers from artefacts being most noticeable with text atop a flat colour, having a major visual impact on source devices such as a PC at 4:4:4, making text blurry. This is also why TV and monitor manufacturers use DSC.
Therefore, when viewing DSC vs original content, VESA® has concluded that the difference is imperceptible to the human eye.
Based on all of this, Klarity chose DSC's superior technology to give you the best HDBaseT 4K60 4:4:4 HDR video quality.
Source
VESA®, Rtings & HDBaseT™
*Company names are trademarks™ or registered® trademarks of their respective holders.
Specifications
- HDBaseT DSC Technology
- Up to 100m/328ft 4K60 4:4:4 18Gbps 10bit HDR
- HDCP 2.2 Compliant
- 8x HDMI 2.0 Inputs + 8x HDBaseT Outputs
- 2x HDMI Loop-Through
- 4K to 1080p built-in Downscaler on all output ports
- Optical S/PDIF & Stereo Phono Input
- 8x Optical S/PDIF Outputs
- 8x Stereo Phono Outputs
- Includes 8 HDBaseT Receivers with Optical S/PDIF & ARC support
- HDBaseT PoE - Receivers require no power
- ARC on all receiver baluns (if the TV has an app such as iPlayer, Netflix, Prime Video, etc, you can watch it on that TV and the audio will go via the matrix and into your local sound system in the same room as that TV).
- HDR10 & HDR10+
- Supports all known audio formats including: Dolby Atmos®, DTS:X®, Dolby TrueHD®, Dolby Digital Plus®, DTS-HD® Master Audio
- Includes: 1 Standard remote control, 1 Easy remote control (easy remote has 9 buttons. When at any TV, if you want to watch for example Source 2, just aim the remote at that TV and press 2 and it will automatically show Source 2 on that TV).
- Directional IR: for example, you are watching Input 3 at TV2, any IR command you give will only send that IR signal to Input 3.
- 3 Years Warranty
